AEROX INDUSTRIES
Dry ice blasting nozzle
Velocity S-Flat Narrow Flat Dry Ice Blasting Nozzle
Choose the pattern. Match the process.
A narrow flat pattern for controlled cleaning on compatible detailed surfaces. The published configuration is intended for smaller particles and moderate airflow.
45 CFM listed maximum1/16 in or smaller ice3/8 in NPT
PURPOSE BUILT FOR YOUR WORK
Features that support the process
01
Direct the blast
Flat precision pattern supports the appropriate cleaning approach.
02
Use a matching connection
Confirm thread size and adapter compatibility with your blasting gun.
03
Set the cleaning intensity
Pressure, particle size and ice feed determine the effect on the surface.
APPLICATIONS
Where it fits
Components and assemblies
Target compatible parts with suitable access and tested settings.
Industrial maintenance
Remove compatible residues from equipment and tooling.
Restoration
Review substrate sensitivity before selecting the nozzle and process.
PRODUCT DETAILS
Specifications at a glance
| Published maximum airflow | 45 CFM |
|---|---|
| Published ice feed maximum | Approx. 11 oz/min |
| Recommended particle size | Approx. 1/16 in or smaller |
| Connection | 3/8 in NPT male |
| Material | Aluminum |
| Adapter | Revive R1 quick disconnect included |
PLAN THE RIGHT SETUP
Selection and operating notes
- Match nozzle demand to sustained compressor airflow and the blaster feed capacity. A nozzle specification does not increase the output of the connected machine.
- Always operate within the lowest rated limit of the complete system. Test the surface and adjust pressure, stand off distance and particle size before full cleaning.
- A fragmenting adapter is recommended on Revive R1 equipment to achieve the smaller particle size required for this nozzle.
