Description

💨 AeroX DryForce 400

420 CFM Industrial Aftercooler & Moisture Control System

12V Powered | 232 PSI Rated | Multi-Stage Separation

Built for Diesel Compressors. Designed for Any High-Demand Air System.

The AeroX DryForce 400 is a high-capacity, 12V-powered aftercooler and multi-stage filtration system engineered to rapidly cool compressed air and remove up to 70% of bulk liquid moisture before it reaches dryers, blasting systems, or pneumatic equipment.

For diesel dry ice blasting, this is essential equipment.
For any high-output compressor, this is serious protection.

❄ Performance & Moisture Removal

Compressed air leaving diesel and rotary screw compressors is extremely hot and fully saturated.

The DryForce 400™:

• Rapidly drops discharge temperature
• Forces condensation
• Removes up to 60–70% of bulk liquid moisture
• Reduces load on downstream dryers
• Protects blasting systems and tools

Actual removal depends on ambient conditions, but properly installed systems consistently remove the majority of condensate before air reaches your dryer.

🔌 12V Cooling System with 15’ Harness

• Dual high-output 12V DC cooling fans
• 95W total fan power
• 15-foot wiring harness with On/Off switch
• Heavy-duty alligator battery clips
• Direct connection to diesel compressor battery
• Compatible with any 12V source
• Plug-and-play integration with AeroX RS60g

The 15’ harness gives you flexibility while encouraging proper placement — the aftercooler should remain close to the compressor discharge for maximum effectiveness.

🔬 Multi-Stage Separation & Filtration

Stage 1 – Radiator Cooling Core

High-efficiency aluminum finned core reduces discharge temperature quickly.

Stage 2 – Condensate Collection Tank

Captures heavy liquid water immediately after cooling.

Stage 3 – High-Flow Air / Water Separator

Removes remaining droplets at full flow capacity.
Rated for 232 PSI.

Stage 4 – Oil & Fine Particulate Filter

• Oil aerosol removal
• Liquid particle removal down to <3 micron
• Solid particle removal down to <3 micron
• Oil carryover after separation: approx. 3 PPM

This final stage protects desiccant dryers and blasting equipment from contamination.

🧱 Industrial Construction

• Welded heavy-duty steel frame
• Locking swivel caster wheels
• Industrial radiator core
• Easy-access drain valves
• Designed for trailer and jobsite use

Weight: approx. 132 lbs

📊 Full Technical Specifications

Model: DryForce 400™
Maximum Flow: 420 CFM
Maximum Operating Pressure: 232 PSI
Recommended Continuous Operating Range: 87–232 PSI
Power Supply: 12V DC
Fan Power: 95 Watts
Harness Length: 15 feet
Inlet / Outlet Port Size: 1-1/4″ FNPT (internal thread)
Liquid Particle Filtration: <3 micron
Solid Particle Filtration: <3 micron
Residual Oil Content After Separation: ~3 PPM
Dimensions: 28″ L × 20″ W × 27.5″ H
Weight: ~132 lbs

Warranty: 1-Year Limited Warranty

🧠 System Placement & Use

Ideal system layout:

Compressor → DryForce 400 → Refrigerated Dryer → Desiccant Dryer → Blaster

The DryForce 400 reduces heat and removes bulk water before it reaches any downstream equipment.

🌎 Not Just for Dry Ice Blasting

While essential for diesel dry ice blasting, this system works with:

• Sand blasting systems
• Media blasting systems
• Industrial pneumatic tools
• Paint operations
• Surface prep equipment
• Any air compressor up to 420 CFM

If your compressor produces hot, wet air — this improves it.

🛡 Warranty

All AeroX air management products include a 1-Year Limited Warranty. Wear items excluded.
